200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil

200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil

    • 200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil
    • 200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil
    • 200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil
    • 200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil
    • 200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil
    • 200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil
  • 200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil

    Détails sur le produit:

    Lieu d'origine: Chine
    Nom de marque: zealchon
    Certification: CE ISO
    Numéro de modèle: DYLE

    Conditions de paiement et expédition:

    Quantité de commande min: 1 ensemble
    Prix: $22000
    Détails d'emballage: Boîte en bois
    Délai de livraison: 7 JOURS
    Conditions de paiement: LC, T/T, Western Union, MoneyGram
    Capacité d'approvisionnement: 100sets / mois
    Contactez
    Description de produit détaillée
    MOTEUR: moteur diesel à cylindre unique 180 à refroidissement hydraulique à quatre temps horizontal Puissance nominale - régime: 5.67KW-2600r / min
    Dispositif de cylindre hydraulique CPT: une force de pénétration nominale de 200KN Force évaluée de traction: 240 kn
    Accident vasculaire cérébral: 570mm

    Product Description

    Soil Hydraulic CPT Static Cone Penetrometers


    Features:

    This CPT truck is used hydraulic excavators and crawler chassis bracing, it can walk in the beach, flood, sand, paddy and other harsh environment to carry out CPT job, icy roads can still walk.

    It has applied the advanced hydraulic technology, using a combination of sub-chip multi-valve, compact structure, small size, easy installation, low pressure loss, overload characteristics of a good relief.
    The CPT car can a machine is not only ideal for static cone penetration test, configure attachment may extend for CPTU (CPTU), since drilling pressuremeter (PMT), Vane (VCT), pressure-velocity (WVT) and other in-situ test trials.

    The biggest advantage: fuel-efficient, saving manpower, high performance, high efficiency Under the country's first fully hydraulic rotary anchoring device (patent number: 201220081488.1 and patent number: 201220081492.8 configuration core barrel and drill Opening hardened concrete pavement etc.) and self-loading and unloading trucks devices (patent number: 201220382939.5), efficient and durable structure Compact, convenient and quick.

    It only needs small power diesel engines for the whole vehicle power system, on a large extent, it reduced the fuel consumption and maintenance costs.

    The operator can boot side edge flapper, safe and save manpower, at least two individuals can be a normal operation, it can greatly improve the work efficiency.

    Parameter
    Engine
    single cylinder 180 diesel engine horizontal four stroke water cooling
    Rated power - speed
    5.67KW-2600r / min
    CPT hydraulic cylinder device
    rated penetration force 200KN
    Rated pull force
    240KN
    Stroke
    570mm
    Weight
    180 kg
    Ground anchor form
    single leaf or multi-leaf anchor anchor
    Maximum working environment Permissible temperature:
    45 ° C
    Supporting probe
    10cm2
    Measuring instruments
    static data collection or automatic collection of European and American brands
    Testing results
    200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil
    200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil
    200kn Tracked Vehicle Soil Hydraulic CPT Static Cone Penetrometers Cptu Investigation Soil
